Standard VFR Equipped - STOL CH 750 LS

AIRFRAME:

ENGINE & ACCESSORIES:

         Aluminum Alloy Monocoque Construction

         “Continental” 0-200 - Factory NEW

         large Cabin Area

         100-bhp @ 2,800 RPM

         All-Moving Rudder (+20 Knots C/W)

         “Sensenich” Propeller

         Heavy Duty Steerable Nosewheel

         Propeller Spinner*

         Super Duty Aluminum Gear

         Carburetor Heat

         Heavy Duty Braking Power

         Super Fast Start Electric Starter

         800x6 Tires & Wheels / Brakes

         Spin-On Oil Filter

         Locking doors with key*

         Huge Inspection Panels

CABIN FEATURES:

         Easily Removable Engine Cowls

         Side-By-Side Seating

         Left & Right Exhaust System

         Huge 50-Inch Wide Cabin

         Easy Access Oil Dip-Stick - NEW

         Cabin Entry From Both Sides

INSTRUMENTATION SYSTEM:

         Air Vents in doors*

          DYNON D10 EMS*

         Large Rear Baggage Compartment

         Hobbs Hour Meter

         Adjustable Shoulder Harness Seat Belts

ELECTRICAL SYSTEM:

         Tough Upholstery

         12 Volt Electrical System

         Cabin room for + 6 1/2 Feet Tall

         12 Volt Gel-Cell Battery
         Cabin heat system*

         Master Switch & Circuit Breakers

CONTROL SYSTEM FEATURES:

         Dual Ignition (Engine)

         Nosewheel – Fully Steerable

         Avionics Master Switch

         Dual Rudder (Pedal) Controls

          ELT*

         Wing Flaperons (Electric)

          Cigarette lighter 12 Volt Outlet*

         Electric Elevator Trim Control

          Alternator

         Dual Hydraulic Toe Brakes*

         Wing Tip Lights and Strobes*

         Vernier Mixture Control

          Tail Light*

         Heavy Duty  Throttle Control



         Carburetor Heat Control


         Single Y control sticks with PPL and trim*

FUEL SYSTEM:



         Easy Access Gascolator



         Fuel Drain Valves

          Note: Does not include any items in the options

         Welded Aluminum Wing Fuel Tanks

                   section of the price list.

         Large Gas Tanks, 24 Gal Total



         Electric Fuel Pump (Auxiliary)


         "Andair" fuel selector valve

PAINT:



         Polyurethane white paint - Tough














* Options included in standard LS for a limited time
